joinsun inr21700-45p 4500mah

INR21700-45P 4500mAh 5~8C High C-rate 5~8C 高倍率

Joinsun INR21700-45P 4500mAh High C-rate 21700 Battery Lithium-ion Cells are certified by UL, CE, CCC, and CB, making them ideal for power banks, portable power stations, mini turbo fan, handheld fan, and more. 吉欣 INR21700-45P 4500mAh 高倍率型锂电芯已通过 UL、CE、中国3C 和 CB 认证，适用于充电宝、户外电源、暴力风扇、手持小风扇等产品。

Joinsun uses BASF's cathode materials for 21700 and 18650 lithium-ion cells Joinsun uses Tinci's electrolyte for 18650 and 21700 lithium-ion cells Joinsun uses SHANSHAN's electrolyte for 18650 and 21700 lithium-ion cells Joinsun uses SEMCORP's separator for 18650 and 21700 lithium-ion cells Joinsun uses GUIBAO's anode material for 21700 and 18650 lithium-ion cells Joinsun uses ZET's anode material for 21700 and 18650 lithium-ion cells

UL Certified Joinsun 21700 / 18650 Lithium-ion Cells FCC Certified Joinsun 21700 / 18650 Lithium-ion Cells CE Certified Joinsun 21700 / 18650 Lithium-ion Cells RoHS Certified Joinsun 21700 / 18650 Lithium-ion Cells IEC Certified Joinsun 21700 / 18650 Lithium-ion Cells CB Certified Joinsun 21700 / 18650 Lithium-ion Cells CCC Certified Joinsun 21700 / 18650 Lithium-ion Cells BSMI Certified Joinsun 21700 / 18650 Lithium-ion Cells PSE Certified Joinsun 21700 / 18650 Lithium-ion Cells BIS Certified Joinsun 21700 / 18650 Lithium-ion Cells

SPECS 规格参数

Model 型号 INR21700-45P
Cathode Material 正极材料 NCM (NMC) 三元
Nominal Capacity 标称容量 4.5Ah (4500mAh)
Nominal Voltage 标称电压 3.6V
Max Charge Voltage 最大充电电压 4.2V
Discharge Cut-off Voltage 放电截止电压 2.75V
Charge Current 充电电流 2.25A (0.5C)
Discharge Current 放电电流 13.5A (3C)
22.5A (5C Pulse)
Nominal Energy 标称能量 16.2Wh
Energy Density 能量密度 669Wh/L
228Wh/kg
Internal Resistance (IR) 内阻 22mΩ ±3
Cycle Life 循环寿命 80% DoD (25°C):
➊ ≥400 Cycles ➊ ≥400 次 Charge 9A (2C) / Discharge 充电: 9A (2C) / 放电: 13.5A (3C)
➋ ≥800 Cycles ➋ ≥800 次 Charge 2.25A (0.5C) / Discharge 充电: 2.25A (0.5C) / 放电: 13.5A (3C)
➌ ≥1000 Cycles ➌ ≥1000 次 Charge 2.25A (0.5C) / Discharge 充电: 2.25A (0.5C) / 放电: 4.5A (1C)
Diameter 直径 21.7±0.15 mm
Height 高度 70.8±0.2 mm
Weight 重量 71±1g
Max Series Connections 最大串联 20
(72V)
Operating Temperature 工作温度 Ambient: 电芯周围环境温度:
Charge: 充电: 0~45°C
Discharge: 放电: -20~60°C

Cell Surface: 电芯表面温度:
Charge: 充电: 0~50°C
Discharge: 放电: -20~80°C
Charge Temperature & Actual Charge Capacity
(Relative to Nominal Capacity) 不同充电温度下的实际充电量
(相对于标称容量) 		0°C: 80%
5°C: 90%
25°C: 100%
45°C: 100%
50°C: 95%
Discharge Temperature & Actual Discharge Capacity
(Relative to Nominal Capacity) 不同放电温度下的实际放电量
(相对于标称容量) 		-20°C: 65%
-10°C: 80%
0°C: 85%
25°C: 100%
45°C: 99%
60°C: 97%
Discharge Rate & Actual Discharge Capacity
(Relative to Nominal Capacity) 不同放电倍率下的实际放电量
(相对于标称容量) 		0.5C: 100%
1C: 97%
2C: 95%
3C: 93%
5C: 90%
Storage Temperature 存储温度 1 Year: 1年: 0~25°C
3 Months: 3个月: 0~45°C
1 Month: 1个月: 0~60°C
(Recovery ≥90% after storage) 储存后的容量恢复率 ≥90%
Certifications 认证 UL, FCC, CE, RoHS, EU Battery Regulation, IEC, CB, CCC, BSMI, BIS, PSE, MSDS, UN38.3
Best Uses 适用 Energy Storage:
Power banks, portable power stations, mini turbo fan, handheld fan 快充形储能: 充电宝，户外电源，移动电源、暴力风扇、便携手持小风扇
OEM / ODM Yes
Warranty 保修 1 Year 1 年
Daily Production Capacity 吉欣工厂日产能 250,000 Cells 25万只


Joinsun Grade-A 21700 / 18650 Lithium-ion Cells
